Kap Shui Mun Bridge

01 Sunday May 2011

Posted by The Tale Of My Heart in Bridges, Construction, Engineering

≈ Leave a comment

Tags

Bridges, Civil Engineering, Construction, Engineering, Hong Kong

The Kap Shui Mun Bridge (KSMB) in Hong Kong was the longest cable-stayed bridge in the world that transports both road and railway traffic (superseded by Oresund Bridge in 2000, with a 490m main span), with the upper deck for motor vehicles, and the lower deck for both vehicles and the MTR. It has a main span of 430 metres and an overall length of 750 metres. It spans the main marine channel, Kap Shui Mun, between Ma Wan and Lantau and provides vertical clearance of 47 metres above sea level.


Span Lengths

The bridge was completed in 1997. The total length of the Kap Shui Mun Bridge includes a 70 m approach span on the Lantau side. A column in each of the back spans of the cable stayed bridge makes four 80 m spans to add to the 430 m main span. This brings the total length to 820 m. The 503 m Ma Wan Viaduct was constructed under the same contract as the KSMB. The viaduct connects the KSMB to the Tsing Ma Bridge, thus forming the Lantau Link that was built to provide access to the new airport.[2] The navigation clearance of 47 m is part of the reason that the H-shaped towers are 150 m tall.

The Kap Shui Mun Bridge is not symmetrical in that the 160 m back span length (80 m + 80 m) is less than half of the main span length (half of 430 m is 215 m). To provide the balance that symmetry will normally provide, the bridge has composite cross sections. The central 387 m of the main span uses steel composite with concrete to make the cross section lighter. The back spans and the remaining main span are concrete cross sections. Using the lighter steel cross section in the majority of the main span serves to equalize the horizontal forces on the towers and balance the bridge.

Because the lower deck carries both rail and traffic, the cross section is designed as aVierendeel truss. This means that there are no diagonal members in the cross section and that vehicles and rail cars drive through the openings provided by the Vierendiel design.

  • Stay cables
  • Number 8 X 22 = 176
    Total length of stay cables 11 km


  • Movements
  • Vertical, at midspan 470mm
    Lateral, at midspan 155mm
    Longitudinal, at Pier 1 320mm

Rate this:

Share

  • Tweet
  • Share on Tumblr
  • Pocket
  • Email
  • Print

Like this:

Like Loading...

Tsing Ma Bridge

30 Saturday Apr 2011

Posted by The Tale Of My Heart in Bridges, Construction, Engineering

≈ Leave a comment

Tags

Bridge, Bridges, Civil Engineering, Construction, Dongguan, Engineering, General contractor, Hong Kong, Humber Bridge, Kap Shui Mun Bridge, Technology, Tsing Ma Bridge, Tsing Yi

The Tsing Ma Bridge, which spans 1377m across the busy Ma Wan Channel, is the second longest bridge in the world after the Humber Bridge in Britain. However, it is the longest bridge that carries both motorway and railway.

There are Five Major Components
in the Construction of the Tsing Ma Bridge:

  1. Foundations and the construction of the bridge tower – one tower located on Tsing Yi side and the other on a man-made island 120 m from the coast of Ma Wan Island. Both towers are 206m above sea level and founded on relatively shallow bedrock. The towers are two-legged with trusses at intervals, in the form of portal beam design. The legs were constructed with high-strength concrete of 100 MPa strength, using a slipform system in a continuous operation.

  2. Anchorages – the pulling forces in the main suspension cables is taken up by large gravity anchorages located at both ends of the bridge. They are massive concrete structures deeply seated on bedrock on the landside of Tsing Yi and Ma Wan island. The total weight of concrete used in the two anchorages is about 300,000 tonnes.

  3. Main cables – The cables were constructed by an aerial spinning process. The process involved drawing wires from a constant-tension supply, and pulling loops of these wires from one anchorage to the other, passing a 500-tonne cast-iron saddle on top of each bridge tower seating the cable. A total of 70,000 galvanised wires of 5.38 mm diameter were placed and adjusted to form the 1.1 m diameter main cable.

  4. Suspended deck – The steelwork for the deck structure was fabricated in Britain and Japan. After delivery, they were further processed and assembled in Dongguan of China into standard deck modules. A total of 96 modules, each 18 m long and about 480 tonnes in weight, were prepared. These deck modules were brought to the site by specially designed barges and raised into the deck position by a pair of strand jack gantries that could manoeuvre along the main cable.

  5. Approach span on Tsing Yi side – similar in form and cross-section to the suspended deck, but the approach span was supported on piers instead of cable-support. The first span was assembled on the ground and raised into position using strand jacks. Further erection then proceeded in cantilever in smaller sections, using derrick cranes stationed on the deck level. An expansion joint which allowed for a maximum thermal movement of 850 mm was also provided and located inside the approach span section.

The Tsing Ma Bridge was designed to carry two three-lane carriageways on the upper deck and two railway tracks on the lower deck. There are also two sheltered single-lane carriageways on the lower deck for maintenance access and as backup for traffic during typhoons when wind speed is still within acceptable limits. The construction cost of Tsing Ma bridge is $7.14 billion and the actual completion time was 57 months.

main contractor
Anglo Japanese Construction/Trafalgar House Construction (Asia) Ltd/
Constain Civil Engineering Ltd/Mitsui & Co Ltd  joint venture



Record-Breaking Island Link



The work base for Tsing Ma Bridge on Tsing Yi Island. This work base comprised concrete batching facilities, a steel handling and fabricating yard, material and equipment storage areas and sub-offices etc.

Partly completed bridge viewed from the main cable and looking towards Ma Wan. The tower of the Kap Shui Mun Bridge can be seen in the background

Partly completed bridge viewed from the main cable and looking towards Tsing Yi.

The Ma Wan Viaduct as seen from the Kap Shui Mun Bridge tower.


The work base for Ma Wan Viaduct on Ma Wan Island. The temporary linking bridge from Ma Wan to the island base of the Tsing Ma Bridge western tower can be seen in the centre of the photo.


Interchange at the Tsing Yi side. In the upper right corner is the expressway leading to the future Ting Kau Bridge which will link the Route 3 Country Park Section to Tsing Yi and Kwai Chung.

Close-up detail of the Interchange. The portal-braced bridge tower can be seen clearly here. The track of the Airport Railway is not visible in this photo as it runs in the lower deck section of Tsing Ma Bridge and, when arriving at the bank on Tsing Yi Island, heads underground.


The 250 m-long approach bridge supported on piers on the Tsing Yi bank, as viewed from the bridge tower.


The connecting section of the steel deck of the approach bridge linked to the coupling structure on the Tsing Yi bank. A derrick crane with a 200 tonne-capacity was positioned on the deck to assist with the lifting of the steel trusses.


Setting up of the derrick crane on the deck top of the approach bridge.



The Ma Wan Viaduct as seen from the Kap Shui Mun Bridge tower.

Joining of approach bridge to the Tsing Yi coupling structure.

Using SGB Alum form to construct the box section of the bridge coupling structure.

Detail of the complicated coupling structure which was built on top of the gravity anchor for the main cable. The three hollow sections inside the coupling structure comprise the connecting tunnel for the airport railway (centre) and the emergency carriage lanes (either side).

The main cable ascending from the cable chamber.

The main cable outside the cable chamber. The hexagonal object seen on the upper side of the cable is the hydraulic cable compacting clamp, the object on the lower side is the cable sorter. The 33,000 separate 5.38 mm galvanised steel wires are sub-divided into 80 strand groups before being tied onto the cable anchor.

Cable strands being tied onto the gravity anchor through adjustable tying bolts. The bolts are anchored to the gravity anchor which is made of mass concrete and weighs some 150,000 tonnes.

Close-up detail of the cable sorter.

A look at the finished cable chamber on the Tsing Yi bank.

External view of the cable chambers on the
Ma Wan side.

The catwalk suspended on the main cable, as seen from the underside. The steel deck of the bridge was still not erected at this stage.

Detail of the 4m-wide catwalk used to access the main cable.

The cast iron cable stay which holds the two pairs of hanging cables for the bridge deck in position. The steel ribbon tapes, located at 1.5 m intervals, are temporary ties for the compacted steel wires that form the main cable.

The final sealing of the main cable. A strong epoxy resin-based paint is used to seal the surface of the cable which is then wrapped with a skin of galvanised iron wire. The rectangular-shaped device is the equipment used to carry out the wire wrapping.

The main cable passing through the saddle on top of the bridge tower.

Close-up of the saddle which holds the turning cable in position. The saddle is made of cast iron and weighs about 500 tonnes.

.
The Ma Wan Viaduct as seen from the Kap Shui Mun Bridge tower.

The work base for Ma Wan Viaduct on Ma Wan Island. The temporary linking bridge from Ma Wan to the island base of the Tsing Ma Bridge western tower can be seen in the centre of the photo.

Interchange at the Tsing Yi side. In the upper right corner is the expressway leading to the future Ting Kau Bridge which will link the Route 3 Country Park Section to Tsing Yi and Kwai Chung.

Close-up detail of the Interchange. The portal-braced bridge tower can be seen clearly here. The track of the Airport Railway is not visible in this photo as it runs in the lower deck section of Tsing Ma Bridge and, when arriving at the bank on Tsing Yi Island, heads underground.

The 250 m-long approach bridge supported on piers on the Tsing Yi bank, as viewed from the bridge tower.

The connecting section of the steel deck of the approach bridge linked to the coupling structure on the Tsing Yi bank. A derrick crane with a 200 tonne-capacity was positioned on the deck to assist with the lifting of the steel trusses.

Setting up of the derrick crane on the deck top of the approach bridge.

Joining of approach bridge to the Tsing Yi coupling structure.

Using SGB Alum form to construct the box section of the bridge coupling structure.

Detail of the complicated coupling structure which was built on top of the gravity anchor for the main cable. The three hollow sections inside the coupling structure comprise the connecting tunnel for the airport railway (centre) and the emergency carriage lanes (either side).

The main cable ascending from the cable chamber.

The main cable outside the cable chamber. The hexagonal object seen on the upper side of the cable is the hydraulic cable compacting clamp, the object on the lower side is the cable sorter. The 33,000 separate 5.38 mm galvanised steel wires are sub-divided into 80 strand groups before being tied onto the cable anchor.

Cable strands being tied onto the gravity anchor through adjustable tying bolts. The bolts are anchored to the gravity anchor which is made of mass concrete and weighs some 150,000 tonnes.

Close-up detail of the cable sorter.

A look at the finished cable chamber on the Tsing Yi bank.

External view of the cable chambers on the
Ma Wan side.

The catwalk suspended on the main cable, as seen from the underside. The steel deck of the bridge was still not erected at this stage.

Detail of the 4m-wide catwalk used to access the main cable.

The cast iron cable stay which holds the two pairs of hanging cables for the bridge deck in position. The steel ribbon tapes, located at 1.5 m intervals, are temporary ties for the compacted steel wires that form the main cable.

The final sealing of the main cable. A strong epoxy resin-based paint is used to seal the surface of the cable which is then wrapped with a skin of galvanised iron wire. The rectangular-shaped device is the equipment used to carry out the wire wrapping.

The main cable passing through the saddle on top of the bridge tower.

Close-up of the saddle which holds the turning cable in position. The saddle is made of cast iron and weighs about 500 tonnes.
The hydraulic jack gantry for lifting the deck unit that works on the main cables.
Close-up look at the gantry showing the two hydraulic jack units on one side with the lifting strands.
Close-up look showing the mounting detail of the gantry. The gantry mounts and moves along the main cables by hydraulic clips. The cables in this case act as the rail for the gantry.
The lifting arrangement as viewed from the bridge tower. The barge with two typical deck units on it was pulled by tug-boats in order to align it into the right posiiton for the final lifting. Rows of hangers from the main cable for hanging the deck units are already in place.
Two typical deck units that weigh about 500 tonnes and measure 41 m x 18 m x 7.8 m; each were delivered to site from Dongguan by barge. The two pairs of lifting strands hanging down from the gantry were in position and ready for lifting.
The lifting arrangement as viewed from the Ma Wan side. The end section of the deck can be seen clearly here.
Positioning of the barge. Two pairs of attaching devices can be seen here on two ends of the deck for the coupling attachment of the lifting strands.
The lifting arrangement as seen from the underside of the partly aligned deck units.
The placing-in of a smaller deck unit that fills an odd gap between the standard decks. These kind of touching-up works are very common at the final stage of the erection.
A 500 mm deviation in level between two deck units before final alignment and adjustment is made.
The supporting detail of the deck to the portal frame of bridge tower. The decks in fact are not rigidly supported on the portal, the main cables supply the actual support. The set-up shows the jack blocks for adjusting the final alignment and level of the bridge deck.
Interior view of the Tsing Ma Bridge. The location as seen here is the airport railway coming out from the reinforced concrete connecting tunnel into the approach bridge on Tsing Yi side.
Workers prepare for the laying of the airport
railway track in the deck interior.
The ties functioned also as the skylight of the airport railway as seen on the deck level. The opening provided by the skylight also acts as a pressure balance to minimise the wind effect during high wind.
The deck of the Tsing Ma bridge is pin-jointed to the reinforced concrete structure of the Ma Wan viaduct at one end and rests on a sliding joint which also acts as the expansion joint at the other end of Tsing Yi. This is one of the pin-joints located on the Ma Wan side.
The Bridge exterior with the stainless steel cladding cover on.
The external look of the bridge deck before the cladding cover is fixed.
Junction of two typical decks as seen from the underside of bridge. A mount-on sliding work platform can be seen here for doing the touch-up works on the bottom part of deck.
Close-up look at the sliding work platforms that are mounted on the bottom of the deck by rail.
The service access inside the approach bridge on Tsing Yi side. The engineering graded UPVC storm water drain can also be seen hanging on the underside of the deck.
Catwalk over the servicing corridor and the multi-decked cable tray. The inner face of the stainless steel cladding cover can also be seen on the right.
The cable tray that houses the control
and power cables inside the servicing
corridor on the sides of the deck interior.
51.500152 -0.126236

Rate this:

Share

  • Tweet
  • Share on Tumblr
  • Pocket
  • Email
  • Print

Like this:

Like Loading...

Ting Kau Bridge

18 Monday Apr 2011

Posted by The Tale Of My Heart in Bridges, Construction

≈ Leave a comment

Tags

Bridges, Construction

Ting Kau Bridge: is a 1,177-metre long cable-stayed bridge in Hong Kong that spans from the northwest of Tsing Yi Island and Tuen Mun Road. It is adjacent to Tsing Ma Bridge which also serves as major connector between the Hong Kong International Airport on Lantau Island and the rest of Hong Kong. It was completed in 1998. The bridge is toll-free.

















The bridge is part of Route 3, connecting North-west New Territories with Hong Kong Island. Other major infrastructures on the road includes Tai Lam Tunnel, Cheung Tsing Tunnel, Cheung Tsing Bridgeand Western Harbour Crossing. Compared to the nearby bridges on Lantau Link, Ting Kau Bridge is not just a landmark structure but also carries the heaviest traffic volume of the bridges, with many container trucks travelling to and from mainland China and the HK container port. A chromatic study and specially designed architectural lighting are intended to set the bridge off in its surroundings.

Ting Kau Bridge, Hong Kong.

Ting Kau Bridge is the world’s first major 4-span cable-stayed bridge. This meant that the central tower had to be stabilised longitudinally, the problem being solved using the longest (465 m) cable stays ever used in a bridge. The design of this bridge contains special features such as single leg towers, which are stabilised by transverse cables just like masts of a sailboat. The Ting Kau Bridge and approach viaducts link the western New Territories and the mainland to an expressway called Lantau Fixed Crossing, which connects the new Airport with Kowloon and Hong Kong. It meets the Lantau Fixed Crossing on Tsing Yi Island only 500 m from the Tsing Ma Bridge.

The Ting Kau Bridge and Approach Viaduct are 1,875 metres long while the triple tower bridge has an overall length of 1,177 metres. Three towers have been specially designed to withstand extreme windand typhoon conditions, with heights of 170 metres, 194 metres, and 158 metres, located on the Ting Kau headland, on a reclaimed island in Rambler Channel (which spans 900 metres wide) and on the north-west Tsing Yi shoreline respectively.

The arrangement of separate decks on both sides of the 3 towers contributes to the slender appearance of the bridge while acting favourably under heavy wind and typhoon loads. Each deck carries 3 traffic lanes and a hard shoulder.

At a design & construction cost of HK$1.94 billion, it is one of the longest cable-stayed bridges in the world. Along with the Tsing Ma and Kap Shui Mun bridges, it is closely monitored by the Wind and Structural Health Monitoring System (WASHMS).

Ting Kau Contractors Joint Venture designed and built Ting Kau Bridge between 1994 and 1998. The joint venture comprised lead partners Cubiertas Y Mzov (22%) and Entrecanales Y Tavora (22%), both of Spain (now both part of Acciona, S.A); Germany’s Ed. Züblin (22%); Australia’s Downer and Co (22%); and Hong Kong’s Paul Y (12%). Constructing engineers were Schlaich Bergermann & Partner



Rate this:

Share

  • Tweet
  • Share on Tumblr
  • Pocket
  • Email
  • Print

Like this:

Like Loading...
Myspace Life Graphics Quotes



Protected by Copyscape Online Copyright Protection

Fire

♡ Latest Posts

  • You Say Madness
  • I Said
  • Being A Jasmine is A Struggle
  • The Flute
  • Intensifier
  • Simply Think!
  • The Legendary Robin Williams R.I.P.
  • RIP Robin Williams
  • Israel is A Nation of Nazis
  • Ramadan Mubarak
  • Just Digging
  • Tears
  • Beach Please
  • Crying Wolf of The West
  • Let’s be Honest
  • RIP Maya Angelou
  • She’s Too Busy
  • دُعَاء‎, Invocation, תפילה
  • Love Will Touch Your Heart
  • Partnership

Enter your email address to follow this blog and receive notifications of new posts by email.

Join 3,531 other followers

Tweet

Google+

Google+

bloggers.com

Just Simply In Love - Find me on Bloggers.com

Facebook

Facebook

Bloglovin

bloglovin

Networked Blogs

Follow this blog

Flup

contact Zahir M Yusuf on flup
Glitter Graphics | http://www.graphicsgrotto.com/

♡ Catagories

♡ Archives

♡ My Stuff

  • Register
  • Log in
  • Entries feed
  • Comments feed
  • WordPress.com
Protected by Copyscape Web Plagiarism Detector
Zahir's bookshelf: read

A Red Herring Without Mustard The Kite Runner Essential Rumi The Book of Love: Poems of Ecstasy and Longing The Prophet A Tear and a Smile

More of Zahir's books »
Book recommendations, book reviews, quotes, book clubs, book trivia, book lists

Bloggers Choice Award

My site was nominated for Best Entertainment Blog!

The Versatile Blogger Award

The Versatile Blogger Award

Liebster Blog Award

7 X 7 Link Award

Kreativ Blogger Award

One Lovely Blog Award

Candle Lighter Award

The HUG Award – as (Hope Unites Globally)

Genuine Blogger Award

ABC Award

Sunshine Award

Very Inspiring Blogger Award

Reader Appreciation Award

Baskets Of Love

Beautiful Blogger Award

One Lovely Blog Award

Reality Blog Award

Blog Of The Year 2012 Award

Wordpress Followed Blog 1000 x Award

I am Part of Wordpress Family Award

Interesting Blog Award

Best Moment Award

Shine On

Wonderful Team Membership Award

Authentic Blog, featured by BlogUpp
blog directory
Iraq Deaths Estimator

♡ Photobucket

Beautiful Hearts And Minds

I'm just starting out; leave me a comment or a like :)

RSS Feed RSS - Posts

RSS Feed RSS - Comments

Brighter Planet's 350 Challenge
Map


Promote Blog
Blog Community & Blog Directory

Top Poetry Sites
Online Marketing
free counters

Blogs I Follow

  • PERCEPTION & AWARENESS
  • PEMBANGUNAN MENERANGI DAN MENCERDASKAN
  • Geniosebi *
  • Furious Curious Cancer Survivor
  • Schnippelboy
  • cocktailmolly
  • unusualbeautyblog.wordpress.com/
  • soulgifts - Telling Tales
  • P e d r o L
  • INDIHOPE
  • 4 Year Old Adult
  • Travel & Liking
  • Koreanish
  • Anne Madeline Designs
  • Gravity and Levity
  • Laura Parrott Perry
  • judgmental observer
  • The Dish
  • Museum in a Bottle
  • Perspectives on Life, the Universe and Everything
  • INNER THOUGHTS
  • Bananas in the Falklands
  • Donncha
  • The Muslim Debate Initiative
  • The little things in beauty
  • Daniel Pátaro
  • ModAlineARTisTree
  • d|gI+Al hEGeM0n ...d|g|Z|nE
  • randommusings
  • Nitrate Diva
  • Jemverse
  • Living a Beautiful Life
  • Hina Khan Palwasha
  • Espen Stenersrød- From Pen To Heart
  • stillness of heart
  • BILAL MURAD
  • Indie Hero
  • forum damani's blog
  • Croatia, the War, and the Future
  • A.D. Martin
  • Plot in Kochi | Kochi Plots | Villas In Kochi | Lands in Kochi |3BHK Appartments In Kochi
  • insidethelifeofmoi
  • ithacalansing.wordpress.com/
  • Pawel Pentlinowski Photography
  • everyday gurus
  • Great Cats of the "World"
  • A Small Act Of Kindness Can Bring Smile On Million Faces
  • Through the Rye
  • Eva thoughts
  • Michael Lee Fitness

♡ My Angels

free counters
My site was nominated for Best Entertainment Blog!
Map

Blog With Integrity

Versatile Blogger Award

Versatile Blogger Award

Liebster Blog Award

Kreativ Blog Award

Kreativ Blog Award

7 X 7 Award

One Lovely Blog Award

Candle Lighter Award

Hug Award

Genuine Blogger Award

ABC Award

Sunshine Award

Pages

  • ♡ Home
  • ♡ Assalamualykum ♡
    • ♡ Me And Scorpion’s ♡
      • ♡ Scorpius
      • ♡ Horoscopes Album 18+
    • ♡ Passion For Constructing Things ♡
  • ♡ Introduction
  • ♡ Spiritual Essence
  • ♡ Dervish
  • ♡ I Love Sports ♡
    • ♡ American Football ♡
      • ♡ Miami Dolphins ♡
    • ♡ Cricket World
      • ♡ Pakistan
      • ♡ England
    • ♡ Football / Soccer ♡
      • ♡ Chelsea F C ♡
      • ♡ Galatasaray
      • ♡ England ♡
    • ♡ Rugby ♡
      • ♡ England ♡
      • ♡ All Blacks ♡
      • ♡ Scotland ♡
    • ♡ Bodybuilding
  • ♡ Inspired By Rumi ♡
  • ♡ My World Of Evolution
  • ♡ Beautiful Mosques Around The World
  • ♡ Wild Life
    • ♡ Lions
    • ♡ Wolf’s
  • ♡ Native American’s
  • ♡ Sign My Cactus Book
  • ♡ Blogger Appreciation Awards
  • ♡ Maya Civilization

♥ Calender

July 2022
M T W T F S S
 123
45678910
11121314151617
18192021222324
25262728293031
« Jan

Allah Angels Anger Arts Beauty Christianity Christians Culture Current Issues Death English Poetry God Happiness Hate Health Heart Hindus History Human Humor Husband Islam Israel Israelis Jews Jokes Jokes Of The Day Just A Rant... Life Lord Love Lovers LOVE SONGS Man Marriage Men Muhammad Music Music Video Music Videos Muslim Muslims Pakistan Palestine Peace Poetry Politics Quotes Qura'n Qura'n and Hadiths Recomendations Recreation Relationship RELATIONSHIPS religion Romance Shopping Song Of The Century Songs Sufi's Truth Uncategorized United States Victory Video Videos war Wars Wife Wisdom Woman Women World Youth Zionists

Beautiful Minds

  • temporarilylostdotcom
  • F. H. Hakansson
  • Palavras Soltas
  • LSCOTT POETRY
  • Tiny Toes
  • Akismet Blog
  • The Narcissist's Blog
  • ● Poems 'n Stuff ●
  • My Blog
  • Reflection of a Buddhist Monk
  • The Mad Hatters
  • Jessie Jeanine
  • autumnsunshineandgabrielleangel
  • Keltrustsnoone
  • vampireweather
  • VeehCirra
  • Teyah Dreams
  • Evoking the Deep
  • Nalaik Panda
  • It's My Thoughts
  • authormercedes
  • Word Press
  • wordsfallfrommyeyes
  • I am Ms. Brightside
  • Million minds in my mind…
  • Violets and Cardamom
  • Broken Sparkles
  • Dark Zone
  • Iamforchange's Blog
  • Worldmusic
  • Somkritya
  • Eleonora B
  • The Happiness nest
  • willowdot21
  • allaboutlemon
  • Annalesca's Blog
  • Androgoth
  • Will Of Heart
  • A Fairy Flying High
  • Qui Entertainment Magazine
  • A Traveller's Tale
  • Zazen Life
  • Jenny
  • ĶŔĨŚĤŃĂ'Ś ŤŔĂVĔĹŐĞÚĔ
  • Destination Weddings Greece
  • Lafemmeroar
  • Napkinwriter
  • Kay aka Babygirl
  • РĂŃĎŐŔĂ'Ś βŐX
  • SHERLINE'S WATCHU THINKIN' BLOG
  • BREAK IT DOWN PETE
  • Diary of a Jaded Heart
  • МŶ ĂβŚŐĹÚŤĔ ĎŔĔĂМŚ
  • Nature Turning Against Mankind
  • Millie Ho
  • YA BAKİ ENTEL BAKİ
  • zumpoems
  • zendictive
  • The Fallen Elegy
  • Blogsurfer.us
  • SYED HAROON HAIDER GILANI
  • Sonia G Medeiros
  • Hymn Of Heart
  • AdaLamar's Blog
  • Warrior Poet Wisdom
  • tigergrove
  • Thoughts From A Jaded Heart
  • Thoughtstomull
  • Love is The Answer
  • Goss Coaching
  • annalesca's blog
  • Thoughts Of Life Experience
  • The Accidental Cootchie Mama
  • Deidra Alexander's Blog
  • Miss Demure Restraint
  • spoiled wali
  • Zolemia's Blog
  • Unwrittentruth's Blog
  • Rumpydog
  • poeticjourney251
  • Taste of life by Sabi
  • Granbee
  • Whimsical KT
  • Not Just A Mummy
  • Have A Dream
  • HeartWinds
  • Debbie Adams
  • ♡ The Tale Of My Heart ♡

PERCEPTION & AWARENESS

Attention with intention builds reality

PEMBANGUNAN MENERANGI DAN MENCERDASKAN

Jln Gereja Moria RT25 RW06 Kelurahan Liliba Kupang NTT

Geniosebi *

Xulgumo

Furious Curious Cancer Survivor

I would have beaten any type of cancer

Schnippelboy

Ein Tagebuch unserer Alltagsküche-Leicht zum Nachkochen

cocktailmolly

Lightin Ish Up

unusualbeautyblog.wordpress.com/

soulgifts - Telling Tales

Creating magic with words

P e d r o L

storytelling the world

INDIHOPE

4 Year Old Adult

Life is all about making other's lives beautiful and that is what my objective is

Travel & Liking

Koreanish

Alexander Chee

Anne Madeline Designs

Fashion Illustrations

Gravity and Levity

A blog about the big ideas in physics, plus a few other things

Laura Parrott Perry

We've all got a story to tell.

judgmental observer

film, tv, popular culture, higher ed, unicorns

The Dish

Museum in a Bottle

Alli Burness is a Museum Pilgrim

Perspectives on Life, the Universe and Everything

A NOMAD ON THE LOOSE

INNER THOUGHTS

INNER THOUGHTS

Bananas in the Falklands

Beguiling, Amorous, Nonconformist, Adeptly Needing Arousing Stimulation oh and Fantastic Kisses.

Donncha

Paper and notes everywhere!

The Muslim Debate Initiative

Muslim Debate News, Commentary and Events

The little things in beauty

Welcome!! This blog is all over the place but it's made with love. It's me, my computer and my love for makeup. So let's go on an avanture <3

Daniel Pátaro

ModAlineARTisTree

Creation is the product of synchronizing our energy with the universe. Once we experience the whole and recognize it, we become aware that we are nothing but the Divine Creative Force.

d|gI+Al hEGeM0n ...d|g|Z|nE

An Occult Machine

randommusings

Nitrate Diva

Old Movies. Fresh Takes.

Jemverse

Life in words

Living a Beautiful Life

~ Short Stories, Flights of Fancy and Everyday Anecdotes ~

Hina Khan Palwasha

Espen Stenersrød- From Pen To Heart

Jack Kerouac with a scent of Henry Vaughn

stillness of heart

MUSINGS : CRITICISM : HISTORY : PASSION

BILAL MURAD

GRAPHIC DESIGNER / LOGO DESIGNER / CREATIVE ARTIST

Indie Hero

Brian Marggraf, Author of Dream Brother: A Novel, Independent publishing advocate, New York City dweller

forum damani's blog

Croatia, the War, and the Future

Ina Vukic - Croatia: people, politics, history, economy, transitioning from communism to democracy

A.D. Martin

writing - novels - film - television - video games - other stuff

Plot in Kochi | Kochi Plots | Villas In Kochi | Lands in Kochi |3BHK Appartments In Kochi

Plot In Kochi At Low Cost.Low cost Villas in kochi.low cost plots in kochi.................

insidethelifeofmoi

ithacalansing.wordpress.com/

Just another WordPress.com site

Pawel Pentlinowski Photography

Sky is The Limit

everyday gurus

Everyday, Everywhere We Are Guided Towards Happiness

Great Cats of the "World"

Dedicated to the Great ~Big Cats of the World

A Small Act Of Kindness Can Bring Smile On Million Faces

We upgraded to www.CompassionKindness.com

Through the Rye

hard rock romantic queer wistful beat poetry

Eva thoughts

Perception is key to inspiration and a strong tool for mind development

Michael Lee Fitness

Cardio + Realistic Diet + Weight Training = Amazing Results!!!

  • Follow Following
    • ♥ The Tale Of My Heart ♥
    • Join 3,531 other followers
    • Already have a WordPress.com account? Log in now.
    • ♥ The Tale Of My Heart ♥
    • Customize
    • Follow Following
    • Sign up
    • Log in
    • Report this content
    • View site in Reader
    • Manage subscriptions
    • Collapse this bar


Loading Comments...


You must be logged in to post a comment.

    %d bloggers like this:
